UPDATE 11.01.2015


I want to use Cape Cora as serial .Like this

Therfore ı must mod T-plug connectors of cape cora.. on the bottom.and block one side to to prevent fluid flow.

I made special stop fittings from delrin

and prevented flow of the fluid.

this is the loop of Watercooling, with serial working Cape Cora..



[Chiller3333]

So the interconnection of the single Cape Cora modules will be performed in the exactly same manner I tried to depict earlier.



[arg-ist]

I actually was only interested in the hardware because the cape cora doesn't have that much of cooling performance. Because of its passive cooling design. But I would be interested in the temps you get when your mod is done

I am very curious about those radiators performance too..
but this is not a performance case...
it is a case for daily use.

I have made enough performance cases and new cases on the way…

Worklog http://www.hardwareluxx.de/community/f143/playdoh-silverstone-tj-07-acrylic-pipe-1012476.html
Worklog http://www.hardwareluxx.de/communit...w-edition-acrylic-tubing-upgrade-1027807.html
Worklog http://www.hardwareluxx.de/communit...-watercooled-copper-acrylic-pipe-1028332.html
Worklog http://www.hardwareluxx.de/community/f143/12-angry-men-900-d-case-p1-1002736.html
Worklog http://www.hardwareluxx.de/community/f143/corsair-900-d-watercooled-mmt-case-997564.html
Worklog http://www.hardwareluxx.de/community/f143/jumbo-case-997157.html
Worklog http://www.hardwareluxx.de/community/f143/transformer-case-996669.html

But I want to hear a bit -SOUNDS OF SILENCE - with this case
.
http://www.youtube.com/watch?v=fPo6v0KhBdw
Thanks Dude.



[arg-ist]

update 14.01.2015



Order arrived and the fittings for acrylic tubing are ready.

Monsoon Light Port 90 Rotary Angle Fittings

Monsoon Light Port 90 Rotary Angle Fittings with mounted Monsoon Premium G1/4 Led Plug

Bitspower Case Top Water Fill/ Trough Hole Fittings to pass trough the case

EK-HDC Fittings 16mm G1/4 FOR Acrylic tubing

Bitspower G1/4 Rotary 90 Adapters

and some special fittings of Cape Cora



[arg-ist]

update 17.01.2015

To mount Bitspower Case Top Water Fill and through hole fittings

Pre drilled

And extended to 20 mm in diameter with step drill

Case through hole fittings mounted to control

Case top water fill for reservoir mounted

EK-HDC Fittings 16mm G1/4 mounted to Bitspower through hole fittings.



[flix29]

Why did you use so many different brands of fittings. they all look different...



[arg-ist]

Why did you use so many different brands of fittings. they all look different...

Becouse;
I am a Bitspower fanaticer and use always Bitspower fittings.

But;
I am using acrylic tubing at the ouside of the case not in the case. They must be rigid.
And I dont find the 16mm OD Bitspower Acrylic fittings rigid. They are very slim .

Therefore ı used for the first time EK fittings.


And MONSOON Light Port 90 Rotary angle fittings are the only solution to illuminate with narrow focus 8 degree superbright led plugs that blast into the loop.



[flix29]

makes sense.



[LeXeL]

ok the 16mm OD fittings from bitspower dont look that rigid (i quess they would still work as suposed)
but the ek fittings looks totaly missmatched, i would say the better way to go would be 1/2" or 12mm or 13mm OD tubeing
from the images these fittings should blend in nicely with the bitspower passthroughs


and for the lightports, you can still use the good old bitspower q-rotary
just a stopfitting on top and mayby the monsoon led-plug on one side
but even then the monsoon knurling wont mathe the knurling on the bitspowerparts (like the ek fittings on the bitspower passthroughs atm)
so i would use a normal led-plug and paint the outside in semigloss black and use a normal 5mm 12000mcd with it to get the effect



[arg-ist]

ok the 16mm OD fittings from bitspower dont look that rigid (i quess they would still work as suposed)
but the ek fittings looks totaly missmatched, i would say the better way to go would be 1/2" or 12mm or 13mm OD tubeing
from the images these fittings should blend in nicely with the bitspower passthroughs


and for the lightports, you can still use the good old bitspower q-rotary
just a stopfitting on top and mayby the monsoon led-plug on one side
but even then the monsoon knurling wont mathe the knurling on the bitspowerparts (like the ek fittings on the bitspower passthroughs atm)
so i would use a normal led-plug and paint the outside in semigloss black and use a normal 5mm 12000mcd with it to get the effect

I agree about the wrong choice of EK fittings too…

Bitspower Q rotary was one of my thought . but ı choused monsoon rotaries so that ı can use them at onother mod . 7 Bitspower q rotary is wery diffucult to use..

I am 67 years old , and I know , learning does not end any time…
Thanks Dude.



[arg-ist]

UPDATE 24.01.2015

Fittings for acrylic tubing are ready and it is time to bend 16mm OD acrylics.

but no free time...

Fıllport for reservoir



[arg-ist]

UPDATE (1) 30.01.2015


İt is time to work with acrylic tubes.
To see the difference 12mm OD and 16mm OD acrylic pipes.

bending 16 mm acrylic pipe

bended acrylic pipe

al pipes ready

and some photos with pipes mounted for test.



[v3nom]

Sehr geil



[DARK ALIEN]

Jepp, nice Work.



[LeXeL]

hmm seems like the tubes #3;4 and 5 dont line up with the rest aka the passthroughts and the lightports that are perfectly in line
and now with the tubes in place your fillport looks so missplaced for me, i think i would have placed him under one of the "handles"



[arg-ist]

UPDATE (2) 31.01.2015

Added some photos more.



[Chiller3333]

Looks great.
I am thrilled to see it when it's done.



[arg-ist]

Hi

I must choose liquid color.
I plan to use as color CERULEAN BLUE .

but ı cannt find CERULEAN BLUE FLUID Cann any body help me .

or which color would you use with MAC G5 Case..Thanks



[KurantRubys]

I think some green like this one would look really great with the silver and the black.



[arg-ist]

UPDATE 06.02.2015


I can not decide whether use of pastel or transparent fluids.
I think this is pastel fluid.

I wantt to achieve this in blueish green

With transparent fluids and dyes can ı mix and achieve Ceruluian blue

but it not very easy to achieve cerulian with pastel fluids and dyes…
I need to be patient…



During the color experiments , ı mounted pump-rez combination an XSPC D5 Photon Reservoir/Pump combo

And made connection between bıtspower case through hole fitting and reservoir



[ohjeohje]

any news?



[arg-ist]

any news?

Ofcourse ...but ı am working, at last days , on a micro server case with 3 titan black videocards.



[arg-ist]

I gave a short break due to my illness



[arg-ist]

I gave a short break due to my illness. arg-ist

I turned again to the World…
continue from where I left off going to study.
Adding some photos from the case MAC G5


I have two new MAC G5 cases on the road ..(on the work table)
One test bench MAC G5
And a Jumbo, double MAC G5 case

68

Acrylic tubing in the case ready

a1

a2

a3

a4

a5

The location of PSU.

a6

I used an old smaler semi modular PSU. And made a drawer , storage compartment , for unused cables.

a7

top cover, to hide cables

a8

and the HDD mounted over the cover with an adapter.

A9

I made a 7 station led board

a10

with on of switch.

a11

power cord of PSU
a11a



[Boogeyman1301]

Das Durchhängen der Grafikkarte sieht aber nicht so gesund aus



[Knoddle]

Genau das dachte ich auch gerade



[arg-ist]

Das Durchhängen der Grafikkarte sieht aber nicht so gesund aus

corrected.



[arg-ist]

and organizing sleeved led plug cables of Monsoon Light Port Rotary Fittings

a12

a13

a14

a15

a16

a17

a18

a19

a20

a21

a22



[arg-ist]

To see the result before final

lighting of of the acrylic tubes without fluid.

a23

a24

a25

a26

a27

at this time I must modify myself…and find cerulian blue...

2 weeks late summer holiday … At Fethiye /Turkey
You are invited too…
and then final photos.
