/caps-man channel
add band=2ghz-b/g/n frequency=2437 name=CH6
add band=5ghz-a/n/ac control-channel-width=20mhz extension-channel=XXXX frequency=5180 name="CH36 80Mhz"
/interface bridge
add name=bridge1
/interface ethernet
set [ find default-name=ether1 ] disable-running-check=no
/caps-man security
add authentication-types=wpa2-psk encryption=aes-ccm group-encryption=aes-ccm name=WLAN2
add authentication-types=wpa2-psk encryption=aes-ccm group-encryption=aes-ccm name=WLAN-Guest
add authentication-types=wpa2-psk encryption=aes-ccm group-encryption=aes-ccm name=VOIP
add authentication-types=wpa2-psk encryption=aes-ccm group-encryption=aes-ccm name=IOT
/caps-man configuration
add channel=CH6 country=germany datapath.client-to-client-forwarding=yes datapath.local-forwarding=yes installation=any mode=ap name="WLAN2 2G" security=WLAN2 ssid=WLAN2
add channel="CH36 80Mhz" country=germany datapath.client-to-client-forwarding=yes datapath.local-forwarding=yes datapath.vlan-id=55 datapath.vlan-mode=use-tag guard-interval=any installation=any mode=ap name="VOIP 5G" rx-chains=0,1,2,3 security=VOIP \
ssid=VOIP tx-chains=0,1,2,3
add channel=CH6 country=germany datapath.client-to-client-forwarding=yes datapath.local-forwarding=yes datapath.vlan-id=55 datapath.vlan-mode=use-tag installation=any mode=ap name="VOIP 2G" security=VOIP ssid=VOIP
add channel=CH6 country=germany datapath.client-to-client-forwarding=yes datapath.local-forwarding=yes datapath.vlan-id=66 datapath.vlan-mode=use-tag installation=any mode=ap name="IOT 2G" security=IOT ssid=IOT
add channel=CH6 country=germany datapath.local-forwarding=yes datapath.vlan-id=44 datapath.vlan-mode=use-tag installation=any mode=ap name="WLAN-Guest 2G" security=WLAN-Guest ssid=WLAN-Guest
add channel="CH36 80Mhz" country=germany datapath.client-to-client-forwarding=yes datapath.local-forwarding=yes datapath.vlan-id=66 datapath.vlan-mode=use-tag guard-interval=any installation=any mode=ap name="IOT 5G" rx-chains=0,1,2,3 security=IOT \
ssid=IOT tx-chains=0,1,2,3
add channel="CH36 80Mhz" country=germany datapath.local-forwarding=yes datapath.vlan-id=44 datapath.vlan-mode=use-tag guard-interval=any installation=any mode=ap name="WLAN-Guest 5G" rx-chains=0,1,2,3 security=WLAN-Guest ssid=\
WLAN-Guest tx-chains=0,1,2,3
add channel="CH36 80Mhz" country=germany datapath.client-to-client-forwarding=yes datapath.local-forwarding=yes guard-interval=any installation=any mode=ap name="WLAN2 5G" rx-chains=0,1,2,3 security=WLAN2 ssid=WLAN2 tx-chains=0,1,2,3
/interface list
add name=WAN
add name=LAN
/interface wireless security-profiles
set [ find default=yes ] supplicant-identity=MikroTik
/caps-man manager
set enabled=yes upgrade-policy=suggest-same-version
/caps-man provisioning
add action=create-dynamic-enabled hw-supported-modes=a,an,ac master-configuration="WLAN2 5G" name-format=prefix-identity slave-configurations="IOT 5G,VOIP 5G,WLAN-Guest 5G"
add action=create-dynamic-enabled hw-supported-modes=b,g,gn master-configuration="WLAN2 2G" name-format=prefix-identity slave-configurations="IOT 2G,VOIP 2G,WLAN-Guest 2G"
/interface bridge port
add bridge=bridge1 interface=ether1
/interface list member
add interface=ether1 list=WAN
/ip address
add address=192.168.1.200/24 interface=ether1 network=192.168.1.0
/ip dhcp-client
add interface=bridge1
/ip dns
set servers=192.168.1.1
/ip route
add distance=1 gateway=192.168.1.1
/system clock
set time-zone-name=Europe/Zurich
