Wie lauten die Befehle?
@Gea
Wie läuft so was unter Openindiana mit napp-it
Schaust Du hier
http://www.nexenta.com/corp/static/docs-stable/NexentaStor-UserGuide.pdf
Muss ich noch schauen ob der Procurve LACP kann. Was es so für Sachen gibt ;-)
18.2 Link Aggregation
The appliance fully supports 802.3ad link aggregation, often referred to by its IEEE working
group name of "IEEE 802.3ad". Other terms for link aggregation include "Ethernet trunk", "NIC
teaming", "port channel", "port teaming", "port trunking", "link bundling", "EtherChannel", "Multi-
Link Trunking (MLT)", "NIC bonding", "Network Fault Tolerance (NFT)".
Link aggregation is used to combine multiple physical Ethernet links into one logical link to
increase bandwidth and to protect against failures.
To create a link aggregation, type create network aggregation in NMC. You can show
existing link aggregates in NMC using show network aggregation, as demonstrated here.
nmc:/$ show network aggregation
LINK PORT SPEED DUPLEX STATE ADDRESS
PORTSTATE
aggr1 -- 1000Mb full up
0:4:23:a8:c2:1c --
e1000g0 1000Mb full up
0:4:23:a8:c2:1c attached
e1000g1 1000Mb full up
0:4:23:a8:c2:1d attached
In this example, interface aggr1 is the aggregation of the two physical network interfaces
Page 170
NexentaStor User Guide
e1000g0 and e1000g1. The physical interfaces are then no longer visible for network
administration and monitoring, unless you first destroy the aggregation using the NMC
command
nmc:/$ destroy network aggregation
Aggregation requires the switch to support Link Aggregation Control Protocol (LACP), which is
a method to control the bundling of several physical ports together to form a single logical
channel. LACP allows a network device to negotiate an automatic bundling of links by sending
LACP packets to the peer (a directly connected device that also implements LACP).
-----------------------------
PS: Nun bin ich scheinbar schon Obergefreiter. Darauf glatt ein Entspannungsbier...
