ASUS M4A88TD-M Evo/USB3, 880G
Link Geizhals ab: 87€
Herstellerlink
Spezifikationen:
Code:
[b]CPU[/b]
AMD Supports 45nm CPU
AMD Cool 'n' Quiet™ Technology Socket AM3 ;Phenom™ II/Athlon™ II/Sempron™ 100 Series Processors
[b]Chipsatz[/b]
AMD 880G/SB850
System Bus 5200/Up to ; HyperTransport™ 3.0 MT/s
[b]Memory[/b]
4 x DIMM, 16 GB, DDR3 2000*/1600/1333/1066 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*Due to CPU spec., AMD 100 and 200 series CPUs support up to DDR3 1066Mhz. With ASUS design, this motherboard can support up to DDR3 1333MHz.
**Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
***Refer to www.asus.com for the memory QVL (Qualified Vendors Lists).
[b]Expansion Slots[/b]
1 x PCIe 2.0 x16
2 x PCI e x1
1 x PCI
[b]VGA[/b]
Integrated ATI Radeon™ HD 4250 GPU
SidePort Memory - onboard 128MB DDR3 1333 memory
Dual independent displays support with HDMI/DVI and D-Sub
Supports HDMI with max. resolution 1920 x 1200 (1080P)
Supports DVI with max. resolution 2560x1600 @60Hz
Supports D-Sub with max. resolution 2560x1440 @75Hz
Supports Microsoft® DirectX 10.1, OpenGL 2.0, Shader Model 4.1
Hardware Decode Acceleration for H.264, VC-1, and MPEG-2
Max. shared memory of 1GB
Hybrid CrossFireX™ Support
[b]Storage[/b]
SB850 Chipset
1 x eSATA port (6Gb/s ready)
5 x SATA 6.0 Gb/s ports 0,1,5,10 Support RAID VIA VT6415 PATA controller
UltraDMA 133/100 for up to 2 PATA devices
1 x
[b]LAN[/b]
Realtek® 8111E Gigabit LAN controller featuring AI NET2
[b]Audio[/b] Realtek® ALC 892 8-Channel High Definition Audio CODEC
- Supports 192kHz/ 24bit BD Lossless Sound
- Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-Retasking
- Optical S/PDIF Out port at back I/O
[b]IEEE 1394[/b]
2 VIA® VT6315N controller supports x 1394a ports (1 at mid-board, 1 at back panel)
[b]USB[/b]
2 x USB 3.0 ports (@PCIE USB3 card)
14 x USB 2.0/1.1 ports (8 ports at mid-board, 6 ports at back panel)
[b]ASUS AI Lifestyle Features[/b]
ASUS Xtreme Design
ASUS Hybrid Processor - TurboV EVO
- Turbo Unlocker, Auto Tuning, TurboV, CPU Level UP, and GPU Boost
ASUS Hybrid Switch
- Core Unlocker
- Turbo Key II
ASUS Hybrid OS -- Express Gate
ASUS Power Solutions
- 4+1 Phase Power Design
- ASUS Anti-Surge Protection
- ASUS EPU
ASUS Exclusive Features
- MemOK!
ASUS Quiet Thermal Solution
- ASUS Fanless Design: Heat sink solution
- ASUS FanXpert
ASUS EZ DIY
- ASUS Q-Shield
- ASUS O.C. Profile
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
- Multi-language BIOS
[b]Overclocking Features[/b]
Precision Tweaker - vCore: Adjustable CPU voltage at 0.003125V increment
- vDIMM: 64-step DRAM voltage control
- vChipset (NB): 64-step Chipset voltage control
2
SFS (Stepless Frequency Selection)
- HT tuning from 100MHz up to 550MHz at 1MHz increment
- PCI Express frequency tuning from 100MHz 150MHz at 1MHz
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)
[b]Back Panel I/O Ports[/b]
x DVI
1 x D-Sub
1 x PS/2 Keyboard/Mouse Combo port
1 2 x USB 3.0 ports (@PCIE USB3 card)
6 x USB 2.0/1.1 ports 1 x HDMI
x External SATA
1 (Optical)
x S/PDIF Out 1 x IEEE 1394a
1 x RJ45 port
1 8 Channel Audio I/O
[b]Internal I/O Connectors[/b]
x USB connectors support additional 8 USB 2.0/1.1 ports
4 5 x SATA 6Gb/s connectors
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Power Fan connector
1 x IEEE1394a connector
1 x S/PDIF Out Header
1 x Core Unlocker Switch
1 x Turbo Key II Switch
1 x MemOK! Button
Front panel audio connector
1 x COM connector
1 x LPT connector
1 x Clear CMOS jumper
1 x 24-pin ATX Power connector
1 x 4-pin ATX 12V Power connector
System Panel
x IDE connector
1
[b]BIOS[/b]
16 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a
[b]Manageability[/b]
WOR by Ring,WOL by PME,WOR by PME,WOR by PME
[b]Accessories [/b]
1 x PCIE USB3 card
1 x Ultra DMA 133/100 cable
2 x Serial ATA 6.0Gb/s cables
1 x Q-Shield
1 x User's manual & Support DVD for M4A88TD-M EVO
1 x User's manual & Support DVD for PCIE USB3
[b]Support CD[/b]
Drivers
ASUS Utilities
Anti-virus software (OEM version)
ASUS Update
[b]Form Factor[/b]
uATX Form Factor
9.6 inch x 9.6 inch 24.4 cm x 24.4 cm )Das Bios:
Impressionen:
Übertaktung:
wird nachgereicht
Kühler welche passen oder nicht:
Luftkühlung:
Wasserkühlung:
Bios:
Downloads:
- Bios / Treiber / Handbuch
