EVGA Classified X58 (E759 & E760)
1. Allgemeines:
2. Technische details
141-BL-E759-A1:
Produktpage Hersteller
CPU Socket:
Chipset:
USB:
P-ATA IDE:
S-ATA:
IEEE 1394:
LAN:
Audio:
I/O:
BIOS:
Special Features:
Form Factor:
Supported OS:
Accessories:
- Socket LGA1366 for Intel Bloomfield i7 Processor
- support QPI(quick path interlink) up to 6.4gt/s, base on 20bit-width up to 25.6gb/s
Chipset:
- x58+ich10r chipset (tylersburg) with nvidia nf200 x16
- six 240-pin ddr3 sdram dimm sockets
- support 1.5v ddr3-1066/1333 dimms with triple channel architecture
- support x16 and x8 dimms, non-ecc, dimms
- support up to 24gb system memory
- one pci connectors compliant with pci v2.3
- one pci-express (x1) connectors compliant with pci express 1.0a
- four pci express (x16) connector compliant with pci express 2.0
- first pci-e x16 bandwidth x16 fixed, signal from x58
- second pci-e x16 bandwidth x16 fixed, signal from nf200 x16 channel a.
- third pci-ex16 pci-e x16 bandwidth x16 or x8, signal from nf200 x16 channel b
- fourth pci-ex16 pci-e x16 bandwidth x8, signal from nf200 x16 channel b
USB:
- twelve usb connectors compliant with usb2.0 from embedded usb controller (8 connectors at rear panel)
P-ATA IDE:
- one ide ports (up to 2 ide devices) with udma-33, ata-66/100/133 support from jmb363 controller
S-ATA:
- six S-ATA II ports with up to 300mb/s from chipset with raid 0,1,0+1,5
- four S-ATA II from JMB363 and JMB362 controllers (1 at rear panel from JMB362)
IEEE 1394:
- two ieee 1394 port from ti tsb43ab22a (1 at rear)
LAN:
- two Gigabit ethernet from Realtek RTL8111C Gigabit controller
Audio:
- selectable 2, 6 or 8-ch audio from realtek ALC889 (colay ALC888s,ALC888) HDA compliant codec
- support rear panel spdif, coaxial output
- support front panel audio for mic-in and stereo line-out only
- (front panel line-out electrically shared with rear panel line-out).
- support jack detection for fool-proof audio device installation
I/O:
- onboard fintek 71883 LPC bus i/o controller
- legacy peripheral interface for ps/2 keyboard
- support hardware monitoring for fan speed monitoring, cpu and system temperature.
- intelligent fan speed control for cpu-fan (PWM) for quiet operation
BIOS:
- 8mb flash spi eeprom with award plug & play bios
- support acpi s3 (suspend to ram) mode in acpi compliant o/s
Special Features:
- support kbpo (keyboard power on) function
- support usb resume in s3
- support wake-on-lan by pme
- onboard 80 post-port led display
- onboard button for convenient power-on, reset, reset cmos
- support asynchronous clocking mode
- dual atx12v 8pin power connectors for cpu
- pci-e slots disable jumpers
- v_core, v_dimm, vtt, ioh, cpu pll, qpi pll, ich io, ich ground measure points
- evga control panel via extension cable
Form Factor:
- 300mm x 265 mm x 40mm, E-ATX size, 8 layers pcb
Supported OS:
- Windows XP/Vista/7
Accessories:
- Userís Manual
- User quick guide
- Three Way SLI-bridge cards x 2
- two way flex SLI-bridge card
- IDE-Cable , 6 S-ATA data cable;
- 2 usb+1 1394 bracket cable
- evga control panel & cables
- CD for drivers, utilities and bundle software
- IO shield
141-BL-E760-A1:
Produktpage Hersteller
Baugleich zum E759 jedoch ohne NF200 Chip, d.h. nur 16x/8x/8x 3-Way SLI
und ohne EVGA Control Panel
und ohne EVGA Control Panel
141-BL-E761-A1:
Produktpage Hersteller Noch nicht verfügbar!
Baugleich zum E760 d.h. nur 16x/8x/8x 3-Way SLI
mit EVGA Control Panel
mit EVGA Control Panel
3. Downloads
BIOS Versionen:
E760/E761
E760/E761 Boot CD Iso
E760/E761 .BIN File
E759
E759 Boot CD Iso
E759 .BIN File
4. Details zum X58 chipsatz
5. Luftkühlung
Liste der Passenden Luftk¸hler
6. Wasserkühlung
keine Kompatibilitätsliste vorhanden
7. BIOS Bilder
folgen
8. Bilder des Boards
9. Verpackung
Retail Verpackung mit Schaumstoff Polsterung
10.Preise
Preisvergleich Link
Bitte beachten das E760 und E759 nicht gesondert untergliedert sind!
13. BIOS TEMPLATE
Mother Board ( EVGA X58 Classified )
Drivers ( )
Bios ( )
CPU ( )
CPU Cooler ( )
Memory ( )
PSU ( )
GPU ( )
Drivers ( )
Operating System ( )
Frequency Control
CPU Clock Ratio ( )
CPU Host Frequency (Mhz) ( )
MCH Strap ( )
CPU Uncore Frequency (Mhz) ( )
CPU Clock Skew ( )
Spread Spectrum ( )
PCIE Frequency (Mhz) ( )
Memory Feature
Memory Speed ( )
Memory Control Setting ( )
Memory Frequency ( )
Channel Interleave Setting ( )
Rank Interleave Setting ( )
Memory Low Gap ( )
tCL Setting ( )
tRCD Setting ( )
tRP Setting ( )
tRAS Setting ( )
tRFC Setting ( )
Command Rate ( )
Voltage Control
EVGA VDroop Control ( )
CPU VCore ( )
CPU VTT Voltage ( )
CPU PLL VCore ( )
**IOH PLL VCore ( )
DIMM Voltage ( )
DIMM DQ Vref ( )
QPI PLL VCore ( )
IOH VCore ( )
IOH/ICH I/O Voltage ( )
**BR04 ( NF200) Voltage ( )
**VTT PWM Frequency ( )
**CPU PWM Frequency ( )
**CPU Impedance ( )
**QPI Signal Compensation ( )
ICH VCore ( )
*PWM Frequency ( )
CPU Feature
Intel SpeedStep ( )
Turbo Mode Function ( )
CxE Function ( )
Execute Disable Bit ( )
Virtualization Technology ( )
Intel HT Technology ( )
Active Processor Cores ( )
QPI Control Settings ( )
QPI Link Fast Mode ( )
QPI Frequency Selection ( )
OC Recorvery ( )
Drivers ( )
Bios ( )
CPU ( )
CPU Cooler ( )
Memory ( )
PSU ( )
GPU ( )
Drivers ( )
Operating System ( )
Frequency Control
CPU Clock Ratio ( )
CPU Host Frequency (Mhz) ( )
MCH Strap ( )
CPU Uncore Frequency (Mhz) ( )
CPU Clock Skew ( )
Spread Spectrum ( )
PCIE Frequency (Mhz) ( )
Memory Feature
Memory Speed ( )
Memory Control Setting ( )
Memory Frequency ( )
Channel Interleave Setting ( )
Rank Interleave Setting ( )
Memory Low Gap ( )
tCL Setting ( )
tRCD Setting ( )
tRP Setting ( )
tRAS Setting ( )
tRFC Setting ( )
Command Rate ( )
Voltage Control
EVGA VDroop Control ( )
CPU VCore ( )
CPU VTT Voltage ( )
CPU PLL VCore ( )
**IOH PLL VCore ( )
DIMM Voltage ( )
DIMM DQ Vref ( )
QPI PLL VCore ( )
IOH VCore ( )
IOH/ICH I/O Voltage ( )
**BR04 ( NF200) Voltage ( )
**VTT PWM Frequency ( )
**CPU PWM Frequency ( )
**CPU Impedance ( )
**QPI Signal Compensation ( )
ICH VCore ( )
*PWM Frequency ( )
CPU Feature
Intel SpeedStep ( )
Turbo Mode Function ( )
CxE Function ( )
Execute Disable Bit ( )
Virtualization Technology ( )
Intel HT Technology ( )
Active Processor Cores ( )
QPI Control Settings ( )
QPI Link Fast Mode ( )
QPI Frequency Selection ( )
OC Recorvery ( )
14. Kompatible Netzteile
EVGA schon spitze beim Support.
