Mal paar Sachen zusammengefasst:
"12 Cap" >> Original Package: 6 layer substrate, 12 caps/20 pads decoupling 3.46mm nominal Z height
"30 Cap" >> Alternate Package: 8 layer substrate, 30 caps/30 pads decoupling, 3.75mm nominal Z height
vcore 1,45V, "im EE-package"
Northwood D1 (AEP) 30 cappers are:
SL78X = 2.6C
SL78Y = 2.8C
SL78Z = 3.0C
SL6WU = 3.0C (not all)
SL6WE = 3.0C (not all)
SL6WG = 3.2C (not all)
SL792 = 3.2C
SL793 = 3.4C (all processors)
Dann gibts noch das M0 Stepping, 2400C SL6Z3 und 2800C SL6Z5 "Northwoods", sind aber umgelabelte "broken" P4 EE Gallantins mit deaktivertem L3 cache.
M0 ist verlötet.
