# dmidecode 3.1
Getting SMBIOS data from sysfs.
SMBIOS 3.0.0 present.
Table at 0x000ED300.
Handle 0x0000, DMI type 0, 24 bytes
BIOS Information
Vendor: American Megatrends Inc.
Version: P2.60
Release Date: 06/06/2017
Address: 0xF0000
Runtime Size: 64 kB
ROM Size: 16 MB
Characteristics:
PCI is supported
BIOS is upgradeable
BIOS shadowing is allowed
Boot from CD is supported
Selectable boot is supported
BIOS ROM is socketed
EDD is supported
5.25"/1.2 MB floppy services are supported (int 13h)
3.5"/720 kB floppy services are supported (int 13h)
3.5"/2.88 MB floppy services are supported (int 13h)
Print screen service is supported (int 5h)
8042 keyboard services are supported (int 9h)
Serial services are supported (int 14h)
Printer services are supported (int 17h)
ACPI is supported
USB legacy is supported
BIOS boot specification is supported
Targeted content distribution is supported
UEFI is supported
BIOS Revision: 5.12
Handle 0x0001, DMI type 1, 27 bytes
System Information
Manufacturer: To Be Filled By O.E.M.
Product Name: To Be Filled By O.E.M.
Version: To Be Filled By O.E.M.
Serial Number: To Be Filled By O.E.M.
UUID: 00000000-0000-0000-0000-000000000000
Wake-up Type: Power Switch
SKU Number: To Be Filled By O.E.M.
Family: To Be Filled By O.E.M.
Handle 0x0002, DMI type 2, 15 bytes
Base Board Information
Manufacturer: ASRock
Product Name: AB350 Pro4
Version:
Serial Number: 00000000000000000
Asset Tag:
Features:
Board is a hosting board
Board is replaceable
Location In Chassis:
Chassis Handle: 0x0003
Type: Motherboard
Contained Object Handles: 0
Handle 0x0003, DMI type 3, 22 bytes
Chassis Information
Manufacturer: To Be Filled By O.E.M.
Type: Desktop
Lock: Not Present
Version: To Be Filled By O.E.M.
Serial Number: To Be Filled By O.E.M.
Asset Tag: To Be Filled By O.E.M.
Boot-up State: Safe
Power Supply State: Safe
Thermal State: Safe
Security Status: None
OEM Information: 0x00000000
Height: Unspecified
Number Of Power Cords: 1
Contained Elements: 0
SKU Number: To be filled by O.E.M.
Handle 0x0004, DMI type 9, 17 bytes
System Slot Information
Designation: PCIE1
Type: x1 PCI Express
Current Usage: Available
Length: Short
ID: 17
Characteristics:
3.3 V is provided
Opening is shared
PME signal is supported
Bus Address: 0000:07:00.0
Handle 0x0005, DMI type 9, 17 bytes
System Slot Information
Designation: PCIE2
Type: x16 PCI Express
Current Usage: In Use
Length: Long
ID: 18
Characteristics:
3.3 V is provided
Opening is shared
PME signal is supported
Bus Address: 0000:0c:00.0
Handle 0x0006, DMI type 9, 17 bytes
System Slot Information
Designation: PCIE3
Type: x1 PCI Express
Current Usage: Available
Length: Short
ID: 19
Characteristics:
3.3 V is provided
Opening is shared
PME signal is supported
Bus Address: 0000:05:00.0
Handle 0x0007, DMI type 9, 17 bytes
System Slot Information
Designation: PCIE4_M2_1
Type: x4 PCI Express
Current Usage: In Use
Length: Short
ID: 20
Characteristics:
3.3 V is provided
Opening is shared
PME signal is supported
Bus Address: 0000:01:00.0
Handle 0x0008, DMI type 9, 17 bytes
System Slot Information
Designation: PCIE5
Type: x1 PCI Express
Current Usage: In Use
Length: Short
ID: 21
Characteristics:
3.3 V is provided
Opening is shared
PME signal is supported
Bus Address: 0000:06:00.0
Handle 0x0009, DMI type 9, 17 bytes
System Slot Information
Designation: PCIE6
Type: x1 PCI Express
Current Usage: In Use
Length: Short
ID: 22
Characteristics:
3.3 V is provided
Opening is shared
PME signal is supported
Bus Address: 0000:08:00.0
Handle 0x000A, DMI type 11, 5 bytes
OEM Strings
String 1: To Be Filled By O.E.M.
Handle 0x000B, DMI type 32, 20 bytes
System Boot Information
Status: No errors detected
Handle 0x000C, DMI type 40, 14 bytes
Additional Information 1
Referenced Handle: 0x00a1
Referenced Offset: 0x01
String: MORDOR
Value: 0x00000000
Handle 0x000D, DMI type 18, 23 bytes
32-bit Memory Error Information
Type: OK
Granularity: Unknown
Operation: Unknown
Vendor Syndrome: Unknown
Memory Array Address: Unknown
Device Address: Unknown
Resolution: Unknown
Handle 0x000E, DMI type 16, 23 bytes
Physical Memory Array
Location: System Board Or Motherboard
Use: System Memory
Error Correction Type: Multi-bit ECC
Maximum Capacity: 64 GB
Error Information Handle: 0x000D
Number Of Devices: 4
Handle 0x000F, DMI type 19, 31 bytes
Memory Array Mapped Address
Starting Address: 0x00000000000
Ending Address: 0x007FFFFFFFF
Range Size: 32 GB
Physical Array Handle: 0x000E
Partition Width: 2
Handle 0x0010, DMI type 7, 19 bytes
Cache Information
Socket Designation: L1 - Cache
Configuration: Enabled, Not Socketed, Level 1
Operational Mode: Write Back
Location: Internal
Installed Size: 768 kB
Maximum Size: 768 kB
Supported SRAM Types:
Pipeline Burst
Installed SRAM Type: Pipeline Burst
Speed: 1 ns
Error Correction Type: Multi-bit ECC
System Type: Unified
Associativity: 8-way Set-associative
Handle 0x0011, DMI type 7, 19 bytes
Cache Information
Socket Designation: L2 - Cache
Configuration: Enabled, Not Socketed, Level 2
Operational Mode: Write Back
Location: Internal
Installed Size: 4096 kB
Maximum Size: 4096 kB
Supported SRAM Types:
Pipeline Burst
Installed SRAM Type: Pipeline Burst
Speed: 1 ns
Error Correction Type: Multi-bit ECC
System Type: Unified
Associativity: 8-way Set-associative
Handle 0x0012, DMI type 7, 19 bytes
Cache Information
Socket Designation: L3 - Cache
Configuration: Enabled, Not Socketed, Level 3
Operational Mode: Write Back
Location: Internal
Installed Size: 16384 kB
Maximum Size: 16384 kB
Supported SRAM Types:
Pipeline Burst
Installed SRAM Type: Pipeline Burst
Speed: 1 ns
Error Correction Type: Multi-bit ECC
System Type: Unified
Associativity: 16-way Set-associative
Handle 0x0013, DMI type 4, 48 bytes
Processor Information
Socket Designation: AM4
Type: Central Processor
Family: Zen
Manufacturer: Advanced Micro Devices, Inc.
ID: 0000000000000000000000
Signature: Family 23, Model 1, Stepping 1
Flags:
FPU (Floating-point unit on-chip)
VME (Virtual mode extension)
DE (Debugging extension)
PSE (Page size extension)
TSC (Time stamp counter)
MSR (Model specific registers)
PAE (Physical address extension)
MCE (Machine check exception)
CX8 (CMPXCHG8 instruction supported)
APIC (On-chip APIC hardware supported)
SEP (Fast system call)
MTRR (Memory type range registers)
PGE (Page global enable)
MCA (Machine check architecture)
CMOV (Conditional move instruction supported)
PAT (Page attribute table)
PSE-36 (36-bit page size extension)
CLFSH (CLFLUSH instruction supported)
MMX (MMX technology supported)
FXSR (FXSAVE and FXSTOR instructions supported)
SSE (Streaming SIMD extensions)
SSE2 (Streaming SIMD extensions 2)
HTT (Multi-threading)
Version: AMD Ryzen 7 1700X Eight-Core Processor
Voltage: 1.4 V
External Clock: 100 MHz
Max Speed: 3900 MHz
Current Speed: 3800 MHz
Status: Populated, Enabled
Upgrade: Socket AM4
L1 Cache Handle: 0x0010
L2 Cache Handle: 0x0011
L3 Cache Handle: 0x0012
Serial Number: Unknown
Asset Tag: Unknown
Part Number: Unknown
Core Count: 8
Core Enabled: 8
Thread Count: 16
Characteristics:
64-bit capable
Multi-Core
Hardware Thread
Execute Protection
Enhanced Virtualization
Power/Performance Control
Handle 0x0014, DMI type 18, 23 bytes
32-bit Memory Error Information
Type: OK
Granularity: Unknown
Operation: Unknown
Vendor Syndrome: Unknown
Memory Array Address: Unknown
Device Address: Unknown
Resolution: Unknown
Handle 0x0015, DMI type 17, 40 bytes
Memory Device
Array Handle: 0x000E
Error Information Handle: 0x0014
Total Width: Unknown
Data Width: Unknown
Size: No Module Installed
Form Factor: Unknown
Set: None
Locator: DIMM 0
Bank Locator: CHANNEL A
Type: Unknown
Type Detail: Unknown
Speed: Unknown
Manufacturer: Unknown
Serial Number: Unknown
Asset Tag: Not Specified
Part Number: Unknown
Rank: Unknown
Configured Clock Speed: Unknown
Minimum Voltage: Unknown
Maximum Voltage: Unknown
Configured Voltage: Unknown
Handle 0x0016, DMI type 18, 23 bytes
32-bit Memory Error Information
Type: OK
Granularity: Unknown
Operation: Unknown
Vendor Syndrome: Unknown
Memory Array Address: Unknown
Device Address: Unknown
Resolution: Unknown
Handle 0x0017, DMI type 17, 40 bytes
Memory Device
Array Handle: 0x000E
Error Information Handle: 0x0016
Total Width: 128 bits
Data Width: 64 bits
Size: 16384 MB
Form Factor: DIMM
Set: None
Locator: DIMM 1
Bank Locator: CHANNEL A
Type: DDR4
Type Detail: Synchronous Unbuffered (Unregistered)
Speed: 3200 MT/s
Manufacturer: Micron Technology
Serial Number: 00000000
Asset Tag: Not Specified
Part Number: 000000000000000000
Rank: 2
Configured Clock Speed: 1600 MT/s
Minimum Voltage: 1.2 V
Maximum Voltage: 1.2 V
Configured Voltage: 1.2 V
Handle 0x0018, DMI type 20, 35 bytes
Memory Device Mapped Address
Starting Address: 0x00000000000
Ending Address: 0x007FFFFFFFF
Range Size: 32 GB
Physical Device Handle: 0x0017
Memory Array Mapped Address Handle: 0x000F
Partition Row Position: Unknown
Interleave Position: Unknown
Interleaved Data Depth: Unknown
Handle 0x0019, DMI type 18, 23 bytes
32-bit Memory Error Information
Type: OK
Granularity: Unknown
Operation: Unknown
Vendor Syndrome: Unknown
Memory Array Address: Unknown
Device Address: Unknown
Resolution: Unknown
Handle 0x001A, DMI type 17, 40 bytes
Memory Device
Array Handle: 0x000E
Error Information Handle: 0x0019
Total Width: Unknown
Data Width: Unknown
Size: No Module Installed
Form Factor: Unknown
Set: None
Locator: DIMM 0
Bank Locator: CHANNEL B
Type: Unknown
Type Detail: Unknown
Speed: Unknown
Manufacturer: Unknown
Serial Number: Unknown
Asset Tag: Not Specified
Part Number: Unknown
Rank: Unknown
Configured Clock Speed: Unknown
Minimum Voltage: Unknown
Maximum Voltage: Unknown
Configured Voltage: Unknown
Handle 0x001B, DMI type 18, 23 bytes
32-bit Memory Error Information
Type: OK
Granularity: Unknown
Operation: Unknown
Vendor Syndrome: Unknown
Memory Array Address: Unknown
Device Address: Unknown
Resolution: Unknown
Handle 0x001C, DMI type 17, 40 bytes
Memory Device
Array Handle: 0x000E
Error Information Handle: 0x001B
Total Width: 128 bits
Data Width: 64 bits
Size: 16384 MB
Form Factor: DIMM
Set: None
Locator: DIMM 1
Bank Locator: CHANNEL B
Type: DDR4
Type Detail: Synchronous Unbuffered (Unregistered)
Speed: 3200 MT/s
Manufacturer: Micron Technology
Serial Number: 00000000
Asset Tag: Not Specified
Part Number: 00000000000000
Rank: 2
Configured Clock Speed: 1600 MT/s
Minimum Voltage: 1.2 V
Maximum Voltage: 1.2 V
Configured Voltage: 1.2 V
Handle 0x001D, DMI type 20, 35 bytes
Memory Device Mapped Address
Starting Address: 0x00000000000
Ending Address: 0x007FFFFFFFF
Range Size: 32 GB
Physical Device Handle: 0x001C
Memory Array Mapped Address Handle: 0x000F
Partition Row Position: Unknown
Interleave Position: Unknown
Interleaved Data Depth: Unknown
Handle 0x001E, DMI type 127, 4 bytes
End Of Table
