EVGA x58 SLI LE
1. Technische Details
Performance
Based on Intel X58/ICH10R chipset
Supports Intel Core i7 Processors
133 Mhz QPI
Memory
6 x 240-pin DIMM sockets
Triple Channel DDR3
Maximum of 12GB of DDR3 1600MHz+
Expansion Slot
4 x PCIe x16/x8/x4, 1 x PCIe x1, 1 x PCI
1 x 32-bit PCI, support for PCI 2.1
Storage I/O
0 x UltraDMA133
6 x Serial ATA 300MB/sec with support for RAID 0, RAID1, RAID 0+1, RAID5, JBOD
Integrated Peripherals
8 Channel High Definition
10/100/1000
Multi I/O
1 x PS2 Keyboard
12 x USB2.0 ports (8 external + 4 internal headers)
Audio connector (Line-in, Line-out, MIC)
FireWire 1394A
Form Factor
ATX Form Factor
Length: 12in � 304.8mm
Width: 9.6in - 243.6mm
2. Der X58 Chipsatz
3. Wasserkühlung
EK-Fullcover Prototyp
Mips
4. Bilder des Boards
5. Verpackung
Die Verpackung ist wie immer von EVGA perfekt es gibt mehrere Schutzsiegel und alles ist gut gepolstert.
6. BIOS
Bios-Template
Frequency/Voltage Control:
Dummy OC [disabled]
Extreme cooling [disabled]
>Memory Feature:
Memory SPD [Standard]
Memory Control Setting [Enabled]
Memory Frequency []
Target Memory Frequency [Mhz]
Channel Interleave Setting [6 Way]
Rank Interleave Setting [4 Way]
Memory Low Gap [Auto]
Parameters
tCL Setting [auto]
tRCD Setting [auto]
tRP Setting [auto]
tRAS Setting [auto]
tRFC Setting [auto]
Command Rate [auto]
>Voltage Control:
EVGA VDroop Control [With VDroop]
CPU VCore [auto]
CPU VTT Voltage [auto]
CPU PLL VCore [auto]
QPI PLL VCore [auto]
DIMM Voltage [auto]
DIMM DQ Vref [+0mV]
IOH VCore [auto]
IOH/ICH I/O Voltage [auto]
ICH VCore [auto]
>CPU Feature:
Intel SpeedStep [Disabled]
Turbo Mode Function [Enabled]
CxE Function [Disabled]
Execute Disable Bit [Enabled]
Virtualization Technology [Disabled]
*****Logical Processor Setting*****
Intel HT Technology [Enabled]
Active Processor Cores [ALL]
*****QPI Controller Setting*****
QPI Control Settings [Enabled]
QPI Link Fast Mode [Enabled]
QPI Frequency Selection [Auto]
CPU Clock Ratio [20 X]
CPU Host Frequency(Mhz) [133]
Target CPU Frequency []
Target Memory Frequency []
MCH Strap [Auto]
CPU Uncore Frequency(Mhz) [Auto]
CPU Clock Skew [0 ps]
Spread Spectrum [Disabled]
PCIE Frequency(Mhz) [100]
OC Recovery [Disabled]
Bios Fotos kommen noch muss Mein MB erst einbauen
