Für was gibst du so hohe vDimm und NS? Wasn Ram Setting?
- - - Updated - - -
Bei 5G muss ca. 2220 rauskomme. Deine Werte sind niedrig.
Ich habe einfach die Werte vom Vorgänger übernommen. Kann man diese optimieren?
Habe gerade G.Skill 3000er drin als Übergang. 4266er kommen bald.
XI Gene
Ai Overclock Tuner [Manual]
BCLK Frequency [100.0000]
ASUS MultiCore Enhancement [Disabled]
SVID Behavior [Auto]
AVX Instruction Core Ratio Negative Offset [0]
CPU Core Ratio [Sync All Cores]
1-Core Ratio Limit [50]
BCLK Frequency : DRAM Frequency Ratio [Auto]
DRAM Odd Ratio Mode [Enabled]
DRAM Frequency [DDR4-4533MHz]
Xtreme Tweaking [Disabled]
CPU SVID Support [Enabled]
CPU Load-line Calibration [Level 5]
Synch ACDC Loadline with VRM Loadline [Disabled]
CPU Current Capability [140%]
CPU VRM Switching Frequency [Auto]
VRM Spread Spectrum [Auto]
CPU Power Duty Control [T.Probe]
CPU Power Phase Control [Extreme]
CPU Power Thermal Control [120]
CPU VRM Thermal Control [Auto]
DRAM Current Capability [130%]
DRAM Switching Frequency [Auto]
Long Duration Package Power Limit [4095]
Package Power Time Window [Auto]
Short Duration Package Power Limit [4095]
IA AC Load Line [Auto]
IA DC Load Line [Auto]
CPU Core/Cache Current Limit Max. [255.50]
Ring Down Bin [Auto]
Min. CPU Cache Ratio [Auto]
Max CPU Cache Ratio [46]
BCLK Aware Adaptive Voltage [Disabled]
CPU Core/Cache Voltage [Manual Mode]
- CPU Core Voltage Override [1.250]
DRAM Voltage [1.4500]
CPU VCCIO Voltage [1.23125]
CPU System Agent Voltage [1.23750]
